Closed Suction Catheter Child Type with Disconnecting Wedge and Non-Return Valve

Product Categories

MCREAT (GUANGZHOU) BIO-TECH CO.,LTD

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

MOQ : 1,000PCS

Price : US$2.98-US$3.40

Payment Terms : T/T,L/C

Delivery Time : 30Days

OEM : Accept

Sample : Available

Contact Now

Disposable PVC Factory ISO Suction Catheter Supplier Single Use

24-Hour Closed Suction Catheter for Pediatric Use

Continuous Breathing: Simultaneously ventilation
Soft Blue Suction Tip: Reduces damage to the patient while suctioning. After returning the catheter, the tip of the tube is easier for irrigational cleaning.
Y Connector Type: ET "Y" neonatal and pediatric care adapters are available for 5, 6, 7, 8, French sizes closed suction catheter.
Disconnecting Wedge: Designed to equip the wedge with both disconnecting and clipping functions.
For Endotracheal Tube and Tracheostomy Tube: Designed for endotracheal and tracheostomy tube using. Tubes with different length are available.
Prevent Cross Infection: Designed with a protective sleeve to isolate the bacteria inside and help caregivers avoid cross-inflection.
Irrigation Port with Non-Return Valve: The non-return valve prevents backflow leakage during washing and aerosolized secretion contamination.

Instructions for Use

Set up Procedure

Inspect the product before use. Do not use it if the package is not intact.
Open the sealed package and remove the product.
Connect the Endotracheal Tube/Tracheostomy Tube to the Revolvable adapter.
Connect ventilator tube to the Revolvable Ventilator Connector.
Attach the date label to the color ring.
Before suctioning commences, ensure that the cap of the MDI Port and Irrigation Port is closed.
Before suctioning: please ensure that the on-off valve is in the open position. Simply slide the on-off valve to a position which allows the catheter to enter the Endotracheal tube/Tracheostomy tube.

Suctioning Procedure

Caution-always use the recommended vacuum levels. Consider length of suctioning time.

Grip the three-way adaptor in one hand and use the other hand to feed the suction catheter into the Endotracheal tube/Tracheostomy tube to the required depth. Depth markers can be visible through the protective cover for your guidance.
Once the suction catheter is in the desired position/depth depress the vacuum control valve to begin suctioning.
Remove the suction catheter until the protective sleeve is straight.
Repeat steps 1-3 as necessary.
